AXIS Q8685-E PTZ Network Camera – Sometimes you need a slow, steady pan. Other times it’s important to be on the spot in a flash. With the responsive AXIS Q8685-E PTZ Network Camera, you set the pace for unobstructed and far-reaching surveillance of expansive outdoor areas.
Informations about AXIS Q8685-E PTZ Network Camera
Swift and smooth
AXIS Q8685-E lets operators choose between high-speed and ultra-slow pan and tilt movement – from 0.05 to 120 degrees per second. So they get smooth and jerk-free panoramic viewing when they need it and can respond quickly to events. It can operate in extreme temperatures, and it can withstand hurricane-strength winds when it’s in motion of up to 47-meter per second (106 mph), and winds over 60-meter per second (135 mph) when it’s in motion and without sunshield.
Ground-to-sky view
The camera can be column-mounted, on poles or walls for a 360° panoramic view and a ground-to-sky view from -90° to +45°. If the need is to tilt upwards, up to +90°, this can be achieved by mounting the camera housing in an inverted configuration on the positioning unit. The inverted configuration gives a tilt range of -45° to +90°.
Far and wide
With 30x optical zoom and superb pan and tilt capabilities, AXIS Q8685-E delivers long-distance identification and the widest possible field of view in every direction. It has Wide Dynamic Range – Forensic Capture for clarity and detail in scenes with both dark and light areas. And it has Focus recall for instant focus in areas you define. In addition, AXIS Q8685-E will also automatically zoom in on objects detected in pre-defined areas thanks to Advanced Gatekeeper. And AXIS Radar Autotracking for PTZ provides automatic tracking of detected objects. In addition, white LED and illuminator bracket are also available. They can be used to further enhance performance – or as deterrence when used in combination with analytics software that turns them on in response to intruders entering a restricted area.
Technical specifications
Camera
| Image sensor | CMOS |
| Image sensor size | 1/2.8 |
| Sensor size in megapixel | 2.0 |
| Lightfinder | – |
| Wide dynamic range | Forensic Capture |
| Min illumination/ light sensitivity (Color) | 0.2 lux |
| Min illumination/ light sensitivity (B/W) | 0.01 lux |
General
| Built-in IR | – |
| OptimizedIR | – |
| Local storage (memory card slot) | Yes |
| Operating temperature | -50 to 55 °C |
| Outdoor Ready | Yes |
| Vandal rating | – |
| IP rating | IP66 |
| Designed for repaint | Yes |
Analytics
| Autotracking version | Autotracking 1 |
| Orientation aid | – |
Video
| Max video resolution | 1920×1080 |
| Max frames per second | 50/60 |
| Day and Night functionality | Yes |
| Electronic image stabilization | Yes |
Lens
| Focal length | 4.3 – 129 mm |
| Horizontal field of view | 65.6 – 2 ° |
| Vertical field of view | 39 – 1.2 ° |
Pan, Tilt, Zoom
| Pan range | 360 endless |
| Tilt range | -90 to 45, -45 to 90 |
| Guard tour | preset position tour |
| Optical zoom | 30 |
| Digital zoom | 12 |
Compression
| Zipstream | Yes |
| H.264 | Baseline, High, Main |
| H.265 | – |
| Motion JPEG | Yes |
Audio
| Audio Support | – |
| Built-in microphone | – |
System Integration
| Audio detection | – |
| Active tampering | – |
| Alarm inputs/outputs | 4 |
Network
| PoE Class | – |
Security
| Signed firmware | – |
| Secure boot | – |
| TPM | – |
