U3SW24 is a USB 3.0 switcher which allows two USB PCs to share four USB 3.0 devices. It supports ultra-fast USB 3.0 data transfer rates of up to 5Gb/s, and easily switches between systems via push buttons with LED indicating the active computer. It is also plug-n-play compatible, no additional driver installation needed. USB bus powered; no power adapter required.
Features of U3SW24 USB/KVM Switcher 3.0
- Allows 2 computers sharing 4 USB 3.0 peripheral devices.
- Supports super speed USB 3.0 data transfer rates up to 5Gb/s.
- Backward compatible with USB 2.0 and USB 1.1 devices.
- One button, simple switching with LED indicators.
- Plug and play, no additional power supply.
- Note: The switcher can be powered by any USB HOST port.
USB 3.0/5Gbps – 10 Times Faster than USB 2.0
The USB 3.0 switcher allows two users to share four USB 3.0 peripheral devices, with the date transfer rate up to 5Gbps. You don’t need to constantly swap cables or set up complicated network sharing software. It’s ideal for office or home applications if you need to switch between computers.
High Compatibility with More Convenience
The USB 3.0 switcher is compatible with any USB 3.0 peripheral devices such as printer, keyboard, mouse, external hard disk, 4K high resolution webcam, camcorder, digital video camera and more. It is also backward compatible with USB 2.0 and USB 1.1 devices.
Mini Size, Plug-n-play, Seamless Switch
With its compact size and exquisite design, the USB 3.0 switcher is also plug-n-play with no additional driver installation needed. It is built with a physical button and LED indicators on the top panel for easy switching.
Works with Various PC Systems
The USB 3.0 switcher also features great compatibility with Windows 10/8/8.1/7/Vista/XP and Mac OS X, Linux and Chrome OS. It can be powered by any USB HOST port, saving you the hassles of using an extra power cable.
Diagram of U3SW24 USB/KVM Switcher 3.0
Specification of U3SW24 USB/KVM Switcher 3.0
| Video | |
|---|---|
| Input/Output Signal Type | USB 3.0 |
| Maximum Transfer Data Rate |
5Gb/s |
| Control Method | Switch button control |
| General | |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Storage Temperature | -20°C to 70°C (-4°F to 158°F) |
| Humidity | 10% to 90%, non-condensing |
| ESD Protection | Human-body Model: ±8kV (Air-gap discharge)/ ±4kV (Contact discharge) |
| Power Consumption (Maximum) |
0.2W (no-load) 4.5W (one USB 3.0 port) 11.5W (all USB device ports shared) |
| Device Dimension (W x H x D) |
4.13” x 0.63’’ x 2.09”/ 105mm x 16mm x 53.2mm |
| Product Weight | 0.28kg/0.62lb |
