Bộ kéo dài KVM HDMI 4K qua IP/TCP, hoạt động 16 bộ trong cùng mạng. AV Access 4KIP100-KVM

Features of 4KIP100-KVM  HDMI Extender

• IP based, 1 Gigabit network support 4K video
• Supports video resolution up to 4K@30Hz
• Supports HDCP 1.4
• Supports 7.1-channels audio

• Supports EDID limited copy
• Supports the distance up to 120m (395ft) with Cat 5e/6/6a/7 cable, with network switch, the distance will be extended unlimitedly

• Supports 3 USB 2.0 for full feature USB 2.0 applications
• Supports 4-Pin DIP switch for more sets works in a same network, up to 16 sets

4K UHD & Zero Latency

A pair of transmitter and receiver can be directly connected, extending 4K@30hz HDMI video over single Cat5e/6 cable up to 120m/390ft with zero latency. It transmits high-quality picture without any video loss and time delay.

Ideal for KVM Applications

You can remotely control PC, PS or Xbox with up to three USB2.0 peripherals, such as keyboard, mouse, microphone, camera, etc. The extender can transmit high-speed USB2.0 signal up to 120m/390ft via single Cat X cable.

Multi-User Control of Remote Systems

Up to 16 sets of transmitter and receiver can work together via a standard Gigabit ethernet switch without the VLAN settings. It is ideal for control centers, especially data control centers and video surveillance centers, where multiple operators can have concurrent access to their respective remote computer/server from their local console.

To route the signal from a transmitter to a receiver, you just need to toggle each individual switches of the DIP switch on the decoder to the same positions as these in the encoder.

Note: This KVM over IP solution only supports point-to-point configuration; one transmitter can only be paired with one receiver.

Excellent Audio Enjoyment

The IP extender supports audio formats such as PCM 2.0/2.1/5.1/7.1, Dolby Digital 5.1 ch, Dolby Digital Plus, Dolby True HD, DTS 5.1 ch, DTS-HD Master Audio, etc., so you can get fantastic audio experience.

Wonderful Gaming Experience with 1080P@120hz

For e-sports games where every second counts, low refresh rate can cause picture lag, greatly affecting the player’s performance. The KVM extender supports 1080P@120Hz video input, ensuring your game sources can be effectively extended. With the KVM extender, you can have an unprecedentedly enjoyable gaming experience.
