AXIS Q6074 PTZ Network Camera is a robust, high-performance PTZ camera that offers superior light-sensitivity for clear, sharp overviews and excellent details in demanding light conditions. It’s ideal for mission-critical surveillance in wide, open, indoor areas such as airports, train terminals and shopping malls. Featuring the new generation Axis chip, it includes enhanced security features such as signed firmware and secure boot.
Informations about AXIS Q6074 PTZ Network Camera
AXIS Q6074 offers 30x optical zoom, superior video and excellent details in HDTV 720p resolution. It features Lightfinder 2.0 which captures low-light images with more saturated colors and sharper images of moving objects. And, Zipstream with support for H.264 and H.265 preserves all the important forensic detail you need, while significantly lowering bandwidth and storage requirements.
This top-of-the-line camera contains all the functionality you need to track and identify suspect behavior. It offers autotracking 2 with click and track functionality for active object tracking. Additionally, it includes an orientation aid with support for dynamic overlays for quick orientation. It comes with AXIS Guard Suite analytics for detecting motion, intrusion and loitering. Furthermore, where privacy must be kept, privacy masking with mosaic lets you pixelate whole areas such as a neighboring property.
Thanks to the newest generation of Axis chip, AXIS Q6075 is packed with advanced security features to prevent unauthorized access and safeguard your system. Signed firmware and secure boot guarantees that the firmware hasn’t been compromised and ensures only authorized firmware is installed. And if needed, secure boot guarantees the camera is completely free of malware after a factory default. For added peace of mind, it includes a Trusted Platform Module (TPM) that is FIPS 140-2 level 2 certified. This module ensures secure storage of all cryptographic keys and certificates even in the event of a security breach
Technical specifications
Models: AXIS Q6074 50 Hz / AXIS Q6074 60 Hz
Camera
| Image sensor |
CMOS |
| Image sensor size |
1/2.8 |
| Sensor size in megapixel |
1.0 |
| Lightfinder |
Lightfinder 2.0 |
| Wide dynamic range |
WDR |
| Min illumination/ light sensitivity (Color) |
0.1 lux |
| Min illumination/ light sensitivity (B/W) |
0.002 lux |
General
| Built-in IR |
– |
| OptimizedIR |
– |
| Local storage (memory card slot) |
Yes |
| Operating temperature |
0 to 50 °C |
| Outdoor Ready |
– |
| Vandal rating |
– |
| IP rating |
IP52 |
| Designed for repaint |
Yes |
Analytics
| Autotracking version |
Autotracking 2 |
| Orientation aid |
orientation aid PTZ |
Video
| Max video resolution |
1280×720 |
| Max frames per second |
50/60 |
| Day and Night functionality |
Yes |
| Electronic image stabilization |
Yes |
Lens
| Focal length |
4.3-129 mm |
| Horizontal field of view |
63.6 – 2.5 ° |
| Vertical field of view |
38.1 – 1.45 ° |
Pan, Tilt, Zoom
| Pan range |
360 endless |
| Tilt range |
180 |
| Guard tour |
preset position tour |
| Optical zoom |
30 |
| Digital zoom |
12 |
Compression
| Zipstream |
Yes |
| H.264 |
Baseline, High, Main |
| H.265 |
Yes |
| Motion JPEG |
Yes |
Audio
| Audio Support |
Yes |
| Built-in microphone |
– |
System Integration
| Audio detection |
Yes |
| Active tampering |
– |
| Alarm inputs/outputs |
4 |
Security
| Signed firmware |
Yes |
| Secure boot |
Yes |
| TPM |
Yes |
* Some technical specifications may vary depending on which hardware option you choose.
