Aten VM8804 4-Port HDMI Output Board with Scaler

HDMI (3D, Deep Color); HDCP 1.4 Compatible
Built-in scaler on each output port to support the scaling function for different video resolutions
Seamless Switch™– provides continuous video streams, real-time switching and stable signal transmission
Audio-enabled

ATEN VM88042 4-Port HDMI Output Board with Scaler offers an easy way to route any of audio/video sources to any of 4 displays, in combination with an ATEN Modular Matrix Switch.

The VM8804 supports Seamless Switch™ technology that provides video switching in real-time, a built in scaler that handles different video resolutions, and EDID Expert technology for fast smooth switching between displays, giving you the perfect viewing experience. The VM8804 also supports HDMI audio can be extracted and stereo audio that can be embedded.

Package Contents

1x VM8804 4-Port HDMI Output Board with Scaler
4x Terminal Blocks
1x User Instructions

Features

4-port HDMI Output Board that is compatible with the VM1600/VM3200 and can be mixed with modular I/O boards of any type for optimum flexibility
Superior video quality – HDTV resolutions of 480p, 720p, 1080i and 1080p (1920 x 1080)
HDMI (3D, Deep Color); HDCP 1.4 Compatible
Seamless Switch™– provides continuous video streams, realtime switching and stable signal transmission*
Built-in scaler on each output port to support the scaling function for different video Resolutions
Consumer Electronics Control (CEC) support
EDID Expert – selects optimum EDID settings for smooth power-up and the highest quality display
Built-in EDID wizard – provides an easy way to customized EDID settings
Hot-swappable design for easy integration of I/O boards
Audio-enabled, HDMI audio can be extracted and stereo audio can be embedded
* Note: If Seamless Switch is enabled, the video output will not display 3D, Deep Color or interlace (i.e., 1080i) resolution features. To use of these features, you must disable Seamless Switch. Videos may not display within range when Seamless Switch™ or Video Wall is enabled, in which case please adjust the display settings on your device.

Diagram

Specifications

Video Output
Interfaces	4 x HDMI Type A Female (Black)
Impedance	100 Ω
Max. Distance	Up to 15m
Video
Max. Data Rate	6.75 Gpbs (2.25 Gbps Per Lane)
Max. Pixel Clock	225 MHz
Compliance	HDMI (3D, Deep Color) HDCP 1.4 Compatible Consumer Electronics Control (CEC)
Max. Resolution	Up to 1920 x 1200
Audio
Output	4 x Captive Screw Connector, 5 pole * Audio signal type: stereo, balanced/unbalanced.
Power Consumption	23.13W:108BTU
Environmental
Operating Temperature	0 – 40°C
Storage Temperature	-20 – 60°C
Humidity	0 – 80% RH, Non-Condensing
Physical Properties
Housing	Metal
Weight	0.58 kg ( 1.28 lb )
Dimensions (L x W x H)	35.20 x 23.80 x 2.33 cm (13.86 x 9.37 x 0.92 in.)
Carton Lot	2 pcs
Note	For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
